Tripp Lite VGA Over USB Powered Extender Kit

Tripp Lite VGA Over USB Powered Extender Kit allows you to extend a 1920 x 1440 (60Hz) signal up to 350 ft., or a 1024 x 768 (60Hz) signal up to 500 ft.,

when using 24Awg, Solid Wire Cat5e/6 cable, such as Tripp Lute’s N022-01K-GY (Cat5) and N222-01K-GY (Cat6). Ideal for digital signage applications, classroom or auditorium projectors, and more.

Extender draws needed power from a USB connection at the computer…no external AC adapters required. Receiver unit includes Gain adjustment for brightness/darkness control, and Equalization adjustment for sharp, clear images.

Tripp Lite VGA Over USB Powered Extender Kit allow for direct attachment to video equipment…no additional VGA cables required. Kit includes a Transmitter with VGA and USB (power) pigtails, and a Receiver with VGA pigtail.

Also included is a small adjustment screwdriver for the EQ and GAIN controls. Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases.

Specification:

Display Style

• Extender

Color

• Black

Connector A

• RJ45 (FEMALE) (X2)

Connector B

• USB A (MALE)

Side A – Connector 1

• (X2) HD15 (MALE)

Tripp Lite VGA Over USB Powered Extender Kit Key Features;
