Behringer PMP1680S 10-Channel Powered Mixer

The Behringer PMP1680S 10-Channel Powered Mixer delivers up to 1600 watts of power and features that are well suited for public address applications in schools, houses-of-worship, presentations, halls, outdoor events and more.

Key Features

  • 1600 Watts
  • 8 Microphone Inputs
  • 6 Mono Line Inputs
  • 2 Stereo Input Connections

Call for Price

The Behringer PMP1680S 10-Channel Powered Mixer delivers up to 1600 watts of power and features that are well suited for public address applications in schools, houses-of-worship, presentations, halls, outdoor events and more. Behringer’s efficient class-D amplifier technology delivers clean sound and power, and 8 channels feature balanced microphone inputs, 6 line inputs and 2 stereo input channels. Each channel features a 3-band EQ section and a dual (stereo) 7-band graphic EQ also features FBQ feedback detection for minimizing noise caused by feedback. Additional features include a dual 24-bit effects processor and vocal remover feature for karaoke, rehearsals, etc.

  • Ultra-compact rack-mountable 2 x 800-Watt stereo powered mixer (1600-Watt bridged mode)
  • Revolutionary Class-D amplifier technology: enormous power, incredible sonic performance and super-light weight
  • Ultra-compact design at nearly half the depth and weight of conventional powered mixers means no more lugging around dead weight
  • 10-channel mixer section features 6 mono and 2 stereo channels plus separate CD/Tape input/output
  • 2 studio-grade, 24-bit stereo FX processors with 100 awesome presets including reverb, chorus, flanger, delay, pitch shifter and various multi-effects
  • Revolutionary FBQ Feedback Detection system instantly reveals critical frequencies for easy feedback removal
  • 8 high-quality mic preamps with switchable +48 V phantom power for condenser microphones
  • Effective, extremely musical 3-band EQ, switchable Pad, and Clip LEDs on all mono channels
  • Stereo 7-band graphic EQ allows precise frequency correction of monitor and main outputs
  • Voice Canceller function removes singer’s voice from recordings for karaoke applications
  • Selectable stereo (main L/R), double mono (main/monitor) or bridged mono amplifier operation mode
  • Speaker Processing function adjusts frequency response to match professional speaker systems like BEHRINGER EUROLIVE series, etc.
  • Standby switch mutes all input channels during breaks while background music is provided via CD/Tape input
  • Adjustable stereo Aux input for connecting external signal sources
  • Internal switch-mode power supply, noise-free audio, superior transient response and very low power consumption
  • Rack mount brackets included
  • High-quality components and exceptionally rugged construction ensure long life
  • Conceived and designed by BEHRINGER Germany

Power Rating

1600 Watts Bridged Mono
800 Watts x2 Stereo

Mic/Line Inputs

8 Balanced Microphone: 3-pin XLR
6 Balanced Mono Line: 1/4" Phone
2 Balanced Stereo Paired Line: 1/4" Phone

Mains Inputs

1/4" Phone

In-Line Inputs/Returns


Aux Sends

FX Out 1 & 2: 1/4" Phone x2

Aux Returns


BUS (Group) Outputs


Main Output

Main: 1/4" Phone Stereo Paired

Tape I/O

Rec: RCA Phono Stereo Paired

Monitor Outputs

Monitor: 1/4" TRS Phone

EQ Section

Channel: 3-Band EQ
7-Band Stereo Graphic



Channel Level Control

Rotary Pots

Trim/Gain Control

Rotary Pots

Phantom Power



5-Segment Stereo LED

Frequency Response

10Hz to 200kHz

Signal-to-Noise Ratio

110dB / 114dB A-Weighted

Total Harmonic Distortion (THD)

0.001% / 0.0007% A-Weighted

Power Supply

120V ~, 60Hz

Dimensions (HxWxD)

12.40 x 18.11 x 8.66" (315 x 460 x 220mm)


21.8lb (9.9kg)

Packaging Info

Package Weight

25.3 lb

Box Dimensions (LxWxH)

21 x 12 x 8"


There are no reviews yet.

Be the first to review “Behringer PMP1680S 10-Channel Powered Mixer”

  • Behringer PMP1680S 10-Channel Powered Mixer
  • Power Cord
